Cobalt Twist Drill Bit DIN338 Standard

  • TW20414

  • TOOLWAY

Diameter:
1.0mm
1.5mm
2.0mm
2.5mm
3.0mm
3.5mm
4.0mm
4.5mm
5.0mm
5.5mm
6.0mm
6.5mm
7.0mm
7.5mm
8.0mm
8.5mm
9.0mm
9.5mm
10.0mm
10.5mm
11.0mm
12.0mm
12.5mm
13.0mm
14.0mm
16.0mm
SKU:
Availability:
Quantity:
Inquire Add to Basket

Product Description

  • Right-hand cutting, type N

  • High-performance high-speed steel

  • Short, cylindrical

  • 135° Tip

  • Diametral tolerance H8

  • In all rotary and percussion drilling machines

  • In machines for mechanical processing

HSS 135°åˆ‡å‰²è§’

Product install

HSS Twist drill bit install

Product Packing QTY

Product Size Sheet
Art No.Diameter(mm)Working length(mm)Overall Length(mm)Packing
TW20414.0101.012
3410pcs in a Transparent clamshell box
TW20414.0151.5
184010pcs in a Transparent clamshell box
TW20414.0202.024
4910pcs in a Transparent clamshell box
TW20414.0252.53.0
5710pcs in a Transparent clamshell box
TW20414.0303.0336110pcs in a Transparent clamshell box
TW20414.0353.5397010pcs in a Transparent clamshell box
TW20414.0404.0437510pcs in a Transparent clamshell box
TW20414.0454.5478010pcs in a Transparent clamshell box
TW20414.0505.0528610pcs in a Transparent clamshell box
TW20414.0555.5579310pcs in a Transparent clamshell box
TW20414.0606.0579310pcs in a Transparent clamshell box
TW20414.0656.56310110pcs in a Transparent clamshell box
TW20414.0707.06910910pcs in a Transparent clamshell box
TW20414.0757.56910910pcs in a Transparent clamshell box
TW20414.0808.07511710pcs in a Transparent clamshell box
TW20414.0858.5
751175pcs in a Transparent clamshell box
TW20414.0909.0811255pcs in a Transparent clamshell box
TW20414.0959.5811255pcs in a Transparent clamshell box
TW20414.10010.0871335pcs in a Transparent clamshell box
TW20414.10510.5871335pcs in a Transparent clamshell box
TW20414.11011.0941425pcs in a Transparent clamshell box
TW20414.12012.01011515pcs in a Transparent clamshell box
TW20414.12512.51011515pcs in a Transparent clamshell box
TW20414.13013.01011515pcs in a Transparent clamshell box
TW20414.14014.0
108
1605pcs in a plastic tube
TW20414.16016.01201785pcs in a plastic tube


Product Szie Sheet

Diameter(mm)
1.0mm-16mm
Color
Yellow
Material
HSS with 5% Cobalt
Packing
1.0-8.0mm 10pcs in a Transparent clamshell box
8.5-13.0mm 5pcs in a Transparent clamshell box
14-16mm 5pcs in a plastic tube
